Cable with connector
M12, 4 Pin, A-coded, Rated voltage: 125V DC/AC, Rated current: 3A, Contact bearer material: PVC.
| Number of contacts | 4 |
|---|---|
| Rated voltage | 125V DC/AC |
| Rated current | 3A |
| Contact material | Brass (Au plating) |
| Contact bearer material | PVC |
| Housing color | Gray |
| Cable material | φ4.2, PVC |
| Cable color | Gray |
| Temperature | －20℃~＋60℃ (No freezing) |
| Cable conductor | 0.34mm2 / 22AWG |
| Protection class of contact | IP 67 |
