Connector
M12, 4 Pin, A-coded, Rated voltage: 250V DC/AC, Rated current: 4A, Housing material: Nylon.
| Number of contacts | 4 |
|---|---|
| Code | A |
| Rated voltage | 250V DC/AC |
| Rated current | 4A |
| Temperature | -25°C~+80°C (No freezing) |
| Protection class of contact | IP 67 |
| Suitable for AWG | 22AWG |
| Seals for cable OD | φ5.5 mm |
| Housing material | Nylon |
