Cable with connector
M12, 4 Pin, D-coded, Rated voltage: 250V DC/AC, Rated current: 4A, Contact bearer material: Nylon.
| Number of contacts | 4 |
|---|---|
| Rated voltage | 250V DC/AC |
| Rated current | 4A |
| Contact material | Brass (Au plating) |
| Contact bearer material | Nylon |
| Housing color | Black |
| Cable material | ø5.5, PVC |
| Cable color | Gray |
| Temperature | －20℃~＋60℃ (No freezing) |
| Cable conductor | 22AWG |
| Protection class of contact | IP 67 |
