Remote modules
RS-485 Interface.Supports Modbus RTU / ASCII. Isolation voltage: 5000 VDC.Dual watchdog timer.
Free PC software Mindman Utility.
Free PC software Mindman Utility.
- RS-485 Interface.
- Supports Modbus RTU / ASCII.
- LED Indicators.
- Isolation voltage: 5000 VDC.
- Dual watchdog timer.
- Surge, EFT and ESD protection.
- Free PC software Mindman Utility.
| Output | 4, 8, 12 |
|---|---|
| Input | 8, 16 |
| Power consumption | 24VDC |
| Input power | ＋10~＋30VDC |
| Output type | Source/ Sink/ Signal Relay/ Power Relay |
| Input type | 10~30 VDC |
| Input rating (Isolation) | 10~35VDC/1A; 40VDC/200mA; 120VAC/0.5A 30V/1A; 250VAC/5A 30VDC/5A |
| Output rating (max.) | Logic level 0: ＋1 V max. Logic level 1: ＋3.5 ~ 30 V |
| Operation temperature | －20~＋75℃ (No freezing) |
| Isolation voltage | 5000 V DC |
| LED | YES |
| Modbus support | Modbus RTU + Modbus ASCII |
| Watchdog timer | System m & Comm. |
| Size (L×W×H) | 120× 77 × 40 mm (with bracket) |
