2/2 way diaphragm valve
2-way normally closed solenoid valve.Available fluid: Water, air & light oil.
- Direct and multiplex acting, connected diaphragm, normal close.
- Can be operated directly under low pressure.
- Acceptable for customization Viton (130°C) , Silicone (130°C) and EPDM (130°C) for seal plug and diaphragm.
- AC voltage tolerance: ±10%. DC voltage tolerance: ±1%.
- Pipes must be washed neat and clean before fitted.
- A Y-STRAINER has to be installed in the front of solenoid valve, that is best for long life.
- It should be installed horizontally; vertical installation is not advisable.
| Body | Forge brass / Cast bronze |
|---|---|
| Coil | Special copper wire (H) |
| Tube | Stainless steel |
| Spring | Stainless steel |
| Core | Stainless steel |
| Plug | NBR, viton, silicon |
