Slot-Type Photomicrosensor PU-Y974｜Mindman Automation Components
Assembling style: METG2. Detection distance: 6 mm (slot width), Sensing distance: ≤ 0.025 mm. Operating voltage: 5~24 VDC±10%, ripple (p-p) less than 10%. Current consumption: ≤15 mA
| Detection distance | 6 mm (slot width) |
|---|---|
| Standard detection object | Opaque objects larger than 2×0.8 mm |
| Sensing distance | ≤ 0.025 mm |
| Contact type | NPN, PNP |
| Switch mode | Switchable between L.on (Light ON mode) and D.on (Dark ON mode) |
| Indicator light | When an object is detected, the light turns off; when no object is present, the light remains on |
| Response frequency | 2KHz |
| Light source | Infrared LED |
| Operating voltage | 5~24 VDC±10%, ripple (p-p) less than 10% |
| Residual voltage | 1V or below (at a load current of 50mA) |
| Current consumption | ≤15 mA |
| Protection circuit | Reverse power protection |
| Ambient light intensity | Illuminance on the receiving surface: Below 1000 lux |
| Ambient temperature | Operating: –25~+55°C, Storage: –30~+80°C (No condensation and freezing) |
| Ambient humidity | Operating: 5~85%RH, Storage: 5~95%RH (No condensation and freezing) |
| Vibration resistance | 10~2000 Hz, single amplitude 0.75mm, X, Y, and Z directions, Scan time: 15 minutes, Scan times: 10 times |
| Degree of protection | IP50 |
| Case material | ABS |
| Wiring method | Connector |
| Wight | 3 g |
