Cable with connector
M8, 3 Pin, Straight female – Straight male, Rated voltage: 125V DC/AC, Rated current: 3A, Contact bearer material: PVC.
| Number of contacts | 3 |
|---|---|
| Rated voltage | 125V DC/AC |
| Rated current | 3A |
| Contact material | Brass (Au plating) |
| Contact bearer material | PVC |
| Housing color | Gray |
| Cable material | φ3.5, PVC |
| Cable color | Gray |
| Temperature | －20℃~＋60℃ (No freezing) |
| Cable conductor | 0.25mm2 / 24AWG |
| Protection class of contact | IP 67 |
