Lubricator
Port size: 3/4, 1, Max. operating pressure: 1 MPa,Proof pressure: 1.5 MPa.
| Bore No. | 20A, 25A |
|---|---|
| Port size | 3/4, 1 |
| Medium | Air |
| Max. operating pressure | 1 MPa |
| Proof pressure | 1.5 MPa |
| Ambient temperature | －5~＋60℃ (No freezing) |
| Lubricating oil capacity | 175 c.c |
| Min. flow for oil drip | 190 l/min |
| Recommended lubricating oil | Turbine oil ISO-VG32 |
| Weight | 1100g |
UM PU tube
Available color :Transparent(T), Black(B), Blue(BU), Transparent blue(CB), Orange(O), Green(G), Yellow(Y), Red(R), Operating pressure range:116 psi (0.8MPa)(65%RH at 20℃),Ambient temperature:-5~140℉(-15~60℃)(No freezing)
