Air units (F.R.Unit)
Port size: 3/4, 1, Operating pressure range:0.05~1 MPa, Proof pressure: 1.5 MPa.
| Bore No. | 20A, 25A |
|---|---|
| Port size | 3/4, 1 |
| Medium | Air |
| Operating pressure range (※) | 0.05~1 MPa |
| Regulated pressure range | 0.05~0.85 MPa |
| Proof pressure | 1.5 MPa |
| Ambient temperature | －5~＋60℃ (No freezing) |
| Filter element | 40 μm |
| Attachment | Pressure gauge, bracket |
| Weight | 2037g |
| Remark | ※1. Standard unit contains semi-auto-drain function when operating pressure below 0.05 MPa. ※2.Choose auto-drain FMRF300, the pressure range is 0.15 ~ 1 MPa. |
MP50.MP75 High precision digital pressure switch
IP65 enclosure.2-Color digital LCD display.Copy function.Programmable pressure unit: KPa, MPa, kgf/cm2,bar, psi, InHg. Sensor parts & fitting parts: Stainless steel 316L. Corrosive fluid or gas available.
PG Pressure gauge
Port size: 1/16, 1/8, 1/4, Operating pressure range: 0~2 MPa.
UM PU tube
Available color :Transparent(T), Black(B), Blue(BU), Transparent blue(CB), Orange(O), Green(G), Yellow(Y), Red(R), Operating pressure range:116 psi (0.8MPa)(65%RH at 20℃),Ambient temperature:-5~140℉(-15~60℃)(No freezing)
