PLC Control System
Text panel
Text panel(MATP)
PDF
MATP
User guide
MATP
New
Q'ty :
Inquiry
Plug-and-Play.Support start-up screen. RS-485 Interface.Full support MA series control. Resolution : 192 × 64 pixels.
Features
Specification
Order Example
Plug-and-Play.
Support start-up screen.
RS-485 Interface.
Full support MA-1188/1189 series controller.
Resolution : 192×64 pixels.
Dual watchdog timer Surge, EFT and ESD protection.
Brightness :
60cd/m
2
Interface
RS-485
Screen type
4.3“ STN-LCD
Display color
Monochromatic
Backlight
Automatic turn off time is 5 sec (On = do not turn off)
Input power
10 ~ 30 VDC
Resolution
192 × 64 pixels
Display range
96×32 mm
Start-up screen size
108×64 Bmp
Operation temperature
-10~+60℃ (No freezing)
Storage temperature
-20~+70℃ (No freezing)
LCM life
50,000 hours
Brightness
60 cd/m
2
Contrast
Adjustable resistor
Cooling method
Natural air cooling
Size (L×W×H)
158×87×29 mm
