Select the diameter of vacuum pad from the formula of the theoretical suction force .

Pad: Soft type. Pad material: Nitrile rubber, Silicon rubber, Fluorosilicon rubber.

Only supplying compressed air, work piece will be held and raised under suction.

Only supplying compressed air, work piece will be held and raised under suction.

Pad type Soft type
Pad material Nitrile rubber, Silicon rubber, Fluorosilicon rubber
UB Polyurethane tube
Fluid medium: Air, water.
Max. operating pressure: 0.8 MPa

NA/NB Nylon tube
Fluid medium: Air, water, heat medium oil (condition) Max. operasting pressure: 2 MPa
