Air units (F.R.L.Unit)
Components: MAFR402, MAL402, Port size: 3/8, 1/2, 3/4, Operating pressure range: 0.05~1 MPa, Proof pressure: 1.5 MPa.
| Components | MAFR402, MAL402 |
|---|---|
| Bore No. | 10A, 15A, 20A |
| Port size | 3/8, 1/2, 3/4 |
| Medium | Air |
| Operating pressure range (※) | 0.05~1 MPa |
| Proof pressure | 1.5 MPa |
| Regulated pressure range | 0.05~0.85 MPa |
| Ambient temperature | －5~＋60℃ (No freezing) |
| Filter element | Standard:40 μm Option:5 μm,20 μm |
| Lubricating oil capacity | 180c.c. |
| Min. flow for oil drip | 200 l/min |
| Recommended lubricating oil | Turbine oil ISO-VG32 |
| Attachment | Pressure gauge, bracket |
| Weight | 1846 g |
| Remark | ※ Standard unit contains semi-auto-drain function when operating pressure below 0.05 MPa. |
