Air units (F.R.Unit)
Longer case for adapting high efficient auto drain valve.
| Bore No. | 8A,10A |
|---|---|
| Port size | 1/4, 3/8 |
| Medium | Air |
| Operating pressure range (※) | 0.05~1 MPa |
| Proof pressure | 1.5 MPa |
| Regulated pressure range | 0.05~0.85 MPa |
| Ambient temperature | －5~＋60℃ (No freezing) |
| Filter element | Standard:5μm Option:40μm |
| Drain capacity | 40 cm3 |
| Attachment | Pressure gauge (PG-40), bracket |
| Weight | 452 g |
Remark |
※1.Standard Unit contains semi-auto-drain function when operating pressure below 0.05 MPa. ※2.Choose auto-drain FMRF300,the pressure range is 0.15~1MPa. |
