Sealing foam pad
The suction surface is made of sponge (Rectangular ring shaped). Suitable for a wide range of workpieces. Vacuum generator built-in type and vacuum pump compatible type are available. Can be easily installed by sliding it in to the flange mounting plate that is fixed to the robot. Improved operability and safety.
- 2 types of grippers are available: whole surface sponge type and arranged Vacuum Pads type. Suitable for a wide range of workpieces.
- Can be directly connected to EOAT of P.C.D. 31.5, 40, 56, 80, and 100.
- Vacuum generator built-in type and vacuum pump compatible type are available.
- Can be easily installed by sliding it in to the flange mounting plate that is fixed to the robot. Improved operability and safety.
| Number of rows of holes | 5, 7, and 11 rows |
|---|---|
| Fluid medium | Air, Vacuum *1 |
| Operating pressure range | 0.3～0.7MPa (Only for Vacuum Generator spec.) |
| Rated supply pressure | 0.5MPa (Only for Vacuum Generator spec.) |
| Noise | 70dB(A) (Only for Vacuum Generator spec.) |
| Operating vacuum pressure | -100～0kPa (Only for Vacuum Pump compatible spec.) |
| Operating temp. range | 5～50℃ (No freezing) |
| Accessory 1 | Robot flange mounting plate (P.C.D. 31.5, 40, 56, 80, 100), Digital Pressure Sensor with 3-color dual display, Push-in fitting for air piping |
| Accessory 2 | Fixed orifice: Suppresses vacuum degradation due to leakage from non-absorbed areas by attaching an orifice to regulate the flow rate. |
| Remark | *1. "Fluid medium: Vacuum" is only for vacuum pump compatible types. *2. Fixed orifice is available as an option. |
