Air / Mist / Micro mist filter
Port size: 1/4, 3/8, 1/2, Operating pressure range: 0.05~1.5 MPa, Proof pressure: 1.5 MPa.
- MAF403A is designed for draining and removal of foreign matter. (Element: 5μm)
- MAF403D/M is designed for removal of foreign matter as well as oil mist (Element: 0.3μm / 0.01μm)
| Bore No. | 8A, 10A, 15A |
|---|---|
| Port size | 1/4, 3/8, 1/2 |
| Medium | Air |
| Operating perssure range (※) | 0.05~1 MPa |
| Proof pressure | 1.5 MPa |
| Ambient temperature | －5~＋60℃ (No freezing) |
| Filter element | 5 μm, 0.3 μm, 0.01 μm |
| Drain capacity | 75 cm3 |
| Weight | 345 g |
| Remark | ※1. Standard unit contains semi-auto-drain function when operating pressure ※2. Choose auto-drain FMRF300, the pressure range is 0.15~1 MPa. |
