MCKA Clamp cylinder｜Long service life with multiple piping options
Tube I.D. φ 40 (mm). Self-lubricating bush and wearing ring for longer lifetime. Multiple piping location.
- Self-lubricating bush and wearing ring for longer lifetime.
- Multiple piping location.
- Magnetic as standard.
| Acting type | MCKA |
|---|---|
| Tube I.D. (mm) | 40 |
| Operating fluid | Compressed Air |
| Operating pressure range | 0.05~1 MPa |
| Proof pressure | 1.5 MPa |
| Temperature range | －5~＋60℃ (No freezing) |
| Lubrication | Not required |
| Available speed range | 50~500 mm/sec |
| Cushion | With adjustable cushion at both ends |
| Sensor switch | RDC, RQC, RCA |
| Sensor switch band | R*C: BKC-1, RCA: PN-A40 |
