PGV Vacuum pressure gauge | Easy operation, durability, and versatility across industries.
Port size: 1/8, Operating pressure range: -100~0 kPa, Stainless steel case
| Bore No. | 6A |
|---|---|
| Port size | 1/8 |
| Medium | Air |
| Operating pressure range | -100~0 kPa (*) |
| Precision | ASME B class |
| Ambient temperature | –5~+60°C (No freezing) |
| Weight | 50 g |
| Remark | * Do not use for positive pressure, otherwise it will cause damage to pressure gauge. |
