MAER210 Electro pneumatic regulator (Communication type) | Precision control, simpler circuits
The MAER210 Electro-Pneumatic Regulator precisely converts electrical control signals into stable pneumatic pressure, providing accurate stepless pressure regulation for compressed air systems. Featuring a microprocessor-based PID control system, it delivers fast response, stable performance, and high-precision pressure control to improve machine repeatability and process consistency.
Equipped with RS-232 and RS-485 communication interfaces, the MAER210 enables remote parameter setting, pressure monitoring, and seamless integration with PLCs, HMIs, SCADA, and industrial automation systems. It supports flexible digital communication for advanced automation applications and centralized pressure management.
With a maximum flow rate of 1,500 L/min, 1/4" and 3/8" port sizes, IP65 protection, and CE certification, the MAER210 provides reliable performance in demanding industrial environments. It can also be modularly integrated with the MA302 Series Air Preparation Units, simplifying piping design and multi-stage pressure control systems.
Applications: Semiconductor equipment, electronics manufacturing, automated production lines, precision machinery, robotic systems, packaging equipment, inspection systems, laser processing equipment, and smart manufacturing.
- Stepless control of air pressure proportional to an electrical signal.
- Simplify complex pipeline for controlling different pressure.
- MAER210 can be assembled with MA**302 series.
- Achieve high precision pressure control with microcomputer PID.
- Maximum flow rate 1500 L/min (Supply pressure 1.0 MPa, Set pressure 0.6 MPa).
- Comply with IP65 and CE certification.
| Pressure range | 1K, 5K, 9K |
|---|---|
| Bore No. | 8A, 10A |
| Port size | 1/4, 3/8 |
| Medium | Air |
| Proof pressure | 1K: 0.3 MPa 5K, 9K: 1.5 MPa |
| Ambient temperature | +5~+50°C (No condensation) |
| Min. supply pressure | Set pressure+0.1 MPa |
| Max. supply pressure | 1 MPa |
| Setting pressure range | 0.005~0.9 MPa |
| Power supply | Connector: M12 plug, 4-pin, A-coded Voltage: DC24V±10% Current: 180mA or less |
| Precision | Linearity: Within ±1% (F.S.) Hysteresis: Within 0.5% (F.S.) Repeatability: Within ±0.5% (F.S.) Sensitivity: Within 0.2% (F.S.) |
| Temperature characteristics | Within ±0.2% (F.S.)/°C |
| Output pressure display | Precision: ±2% F.S. ±1 digit Min. unit: MPa:0.001, kgf/cm2:0.01, bar:0.01, psi:0.1, kPa:1 |
| Enclosure | IP65 |
| Weight | Main: 410 g Accessories: Bracket: Approx. 86g(B1) , 80g(B2); Power cable connector: Approx. 130g(3m); Communication cable connector: Approx. 140g(3m) |
