MAER310 Electro pneumatic regulator (Communication type) | Precision control, simpler circuits
The MAER310 Electro-Pneumatic Regulator precisely converts electrical control signals into stable pneumatic pressure, providing accurate stepless pressure regulation for compressed air systems. Designed for high-flow precision automation applications, it features a microprocessor-based PID control system that delivers fast response, excellent stability, and high-accuracy pressure control to improve machine repeatability and process consistency.
Equipped with RS-232 and RS-485 communication interfaces, the MAER310 enables remote parameter setting, pressure monitoring, and seamless integration with PLCs, HMIs, SCADA, and industrial automation systems. It supports advanced digital communication for centralized pressure management and smart manufacturing applications.
With a maximum flow rate of 4,000 L/min, 1/4", 3/8", and 1/2" port sizes, IP65 protection, and CE certification, the MAER310 provides reliable performance in demanding industrial environments. It can also be modularly integrated with the MA401/MA403 Series Air Preparation Units, simplifying piping design and multi-stage pressure control systems.
Applications: Semiconductor equipment, electronics manufacturing, automated production lines, precision machinery, robotic systems, packaging equipment, inspection systems, laser processing equipment, assembly automation, and smart manufacturing.
- Stepless control of air pressure proportional to an electrical signal.
- Simplify complex pipeline for controlling different pressure.
- MAER310 can be assembled with MA**401/ 403 series.
- Achieve high precision pressure control with microcomputer PID.
- Maximum flow rate 4000 L/min (Supply pressure 1.0 MPa, Set pressure 0.6 MPa).
- Comply with IP65 and CE certification.
| Pressure range | 1K, 5K, 9K |
|---|---|
| Bore No. | 8A, 10A, 15A |
| Port size | 1/4, 3/8, 1/2 |
| Medium | Air |
| Proof pressure | 1K: 0.3 MPa 5K, 9K: 1.5 MPa |
| Ambient temperature | +5~+50°C (No condensation) |
| Min. supply pressure | Set pressure +0.1 MPa |
| Max. supply pressure | 1 MPa |
| Setting pressure range | 0.005~0.9 MPa |
| Power supply | Connector: M12 plug, 4-pin, A-coded Voltage: DC24V±10% Current: DC24V: 180mA or less |
| Precision | Linearity: Within ±1% (F.S.) Hysteresis: Within 0.5% (F.S.) Repeatability: Within ±0.5% (F.S.) Sensitivity: Within 0.2% (F.S.) |
| Temperature characteristics | Within ±0.2% (F.S.)/°C |
| Output pressure display | Precision: ±2% F.S. ±1 digit Min. unit: MPa:0.001, kgf/cm2:0.01, bar:0.01, psi:0.1, kPa:1 |
| Enclosure | IP65 |
| Weight | Main: 740 g Accessories: Bracket: Approx. 86g(B1) , 80g(B2); Power cable connector: Approx. 130g(3m); Communication cable connector: Approx. 140g(3m) |
